The Single Color LED Booster with the constant voltage design can work with all kinds of constant voltage LED Dimmers. with the black metal shell for better heat dissipation. with one channel output design and the max output current up to 25A, max output power up to 300W on DC12V or 600W on DC24V. the LED Booster will receive and transmit out the PWM signal. in theory, the LED Booster can be connected to numerous. you can control the brightness of many Single LED lights at the same time.


  • Model: HX-AMP-04
  • Working Temperature: -20-60℃
  • Size: 127*41*32mm(L*W*H)
  • Working Voltage: DC12V-24V
  • Output Channel: 1
  • Max Output Current: 25A( 1CH )
  • Max Output Power: 300W (12V) / 600W (24V)
  • Static Power Consumption: <1W
  • Weight: 170g
  • CE, ROHS Passed
  • 3 Years Warranty


1*Single Color LED Booster

LED Strip Booster
